Camera
Image Sensor
2 MP CMOS image sensor
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.005 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s
Day & Night
IR cut filter
Angle Adjustment
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Signal System
PAL/NTSC
Lens
Lens Type
2.7 mm to 13.5 mm
Focal Length & FOV
102.4° to 31°
Lens Mount
Φ14
Image Settings
Brightness, Sharpness, 3D DNR , Mirror, Smart IR
Frame Rate
PAL: 1080p@25fps,NTSC: 1080p@30fps
Day/Night Mode
Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR)
120 dB
Image Enhancement
BLC, HLC
AGC
High/Medium/Low
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
General
Material
Metal
Dimension
256.4 mm × 83.3 mm × 78.2 mm (10″ × 3.2″ × 3″)
Approx. 720 g (1.59 lb.)
Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
Language
English
Power Supply
12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.
Consumption
Max. 7.7 W
IR Range
Up to 70 m
Approval
Protection
IP66
WARRANTY : 2 years
