- Model R2X16A
- Radios :
- • Dual Radio for simultaneous dual-band operation
- • 5 GHz 802.11ac 2×2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
- • 2.4 GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
- Interfaces :
- • Uplink Gigabit Ethernet port (E0), with POE-in support (802.3at/802.3af)
- • Downlink Gigabit Ethernet ports (E1-E3), with POE-out on E3 (802.3af) (3)
- • DC power connector (48V)
- • USB host interface (future use)
- • Bluetooth Low Energy (BLE) radio
- • LED Status indicators (3)
- • Reset/LED control button
- • Kensington security slot
- Antennas : Integrated directional antennas with maximum individual antenna gain of 4.3dBi in 2.4GHz and 6.2dBi in 5GHz
- Dimension : 86mm x 40mm x 150mm
- Power :
- • Power over Ethernet (PoE) on E0: 802.3af (class 3) or 802.3at (class 4). When using 802.3af, POE-out on E3 is disabled
- • Max power consumption (worst-case): 9.7W (PoE/DC) or 25.3W PoE PSE (302.3at PoE/DC)
- • DC power (48V): no restrictions
- • Note: Power sources are sold separately
- Warranty : 2 Years
