- PFS3005-4ET-60
- 5-Port Unmanaged Desktop Switch with 4-Port PoE
- * The parameters and datasheets below can only be applied to V2.0 (version 2.0)
- > Intelligent PoE
- > Hi-PoE 60W (orange port)
- > 8-pin assignment PoE power supply
- > Long distance PoE
- > PoE watchdog
- > Wide working temperature
- Hardware Feature
- Ethernet Port Port 1-4: 4 × RJ-45 10/100M (PoE)
- Port 5: 1 × RJ-45 10/100M (uplink)
- PoE Power Consumption Port 1 ≤ 60 W (Hi-PoE)
- port 2-4 ≤ 30 W
- total ≤ 60 W
- Power Consumption Idling: 0.8 W
- Full load: 60 W
- Standard IEEE802.3, IEEE802.3u, IEEE802.3x
- PoE
- PoE Protocol IEEE802.3af/ IEEE802.3at/ Hi-PoE
- Power Supply Pin 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
- Long Distance 250 m long distance PoE transmission
- PoE Power Management Yes
- PoE Watchdog Yes
- Performance
- Switching Capacity 1.8 Gbps
- Packet Forwarding Rate 744 Kbps
- Packet Buffer Memory 1 Mbit
- Flow Control Enable by default
- Working Temperature –10 °C to +55 °C (+14 °F to +131 °F)
- Application Humidity 5%– 95% (RH)
- General
- Power Input 48 V – 57 V DC
- Lighting Protection Common mode: 4 kV
- Differential mode: 2 kV
- ESD Protection Air discharge: 8 kV
- Contact discharge: 6 kV
- Wall-mount Installation Yes
- Anti-theft Lock Hole Yes
- Weight 0.30 kg (0.64 lb)
- Dimension 130 mm × 85 mm × 26 mm (5.12″” × 3.35″” × 1.02″”)
- Warranty 2 year
PFS3005-4ET-60
| Brand |
Dahua |
|---|
